If the system-event type is `Alarm’ | `Trouble’ | `Supervisory’, the appropriate LED blinks. The event is displayed, the local audible sounds, and the tab on the display for the corresponding event queue flashes. When an event occurs in the system, the display enters the `Alert’ mode. Operation In normal | standby condition, a Model FCM2041-U3 OI displays the site-specific, customized message the time and date, and a rundown of the system status.
Under a single part number, S54430-C16-A1. NOTE: Alternate-language labels are orderable Slide-in tab to apply corresponding label (for non-English text) Operator Interface Unit mounted in a Model CAB1 enclosureĭata Sheet 8350 /cerberus-pro NOTE: Alternate-language labels are ordered separately.
Slide-in labels are orderable under a single part number for applications that require French (Canadian) | Spanish | Portuguese-Brazilian text. A 40-inch (1.02m) long 60-pin wire cable, P/N 555-133743, is used to connect a Cerberus PRO Modular Operator Interface, Model FCM2041-U3 to the Siemens five-slot card cage, Model CC-5. Additional diagnostic displays can be found at the back end of each Model FCM2041-U3 to provide efficiency to the end-user in troubleshooting the Cerberus PRO Modular fire-alarm control panel (FACP). Keys are also readily available in order for the end user to obtain help information, as well as to enter into the menu features of a Model FCM2041-U3 OI. The display is surrounded by keys that are used to control the displayed information and to navigate through these screens. An audible sounds from a Model FCM2041-U3 operating unit when there are unacknowledged events.
#Cerberus pro ul listed full#
Specifications Each Cerberus PRO Modular Operator Interface contains a full liquid-crystal display (LCD) at the front end.
#Cerberus pro ul listed software#
It is through the custom-configuration software tool, Zeus-C, that Model FCM2041-U3 OIs are able to provide programmed logic and panel supervision. Additionally, remote, multi-module-mounted enclosures for Cerberus PRO Modular, Models REMBOX2 and REMBOX4, can each house one (1) Model FCM2041-U3 OI. In terms of hardware used for Cerberus PRO Modular, Model FCM2041-U3 Operator Interfaces can be mounted in full-size CAB1 | CAB2 | CAB3 enclosures. – intelligent detectors | notification appliance circuits ), and reset the system. Model FCM2041-U3 provides straightforward, front-end access for an end-user to perform system tasks, such as: acknowledge events control addressable points (e.g. Product Overview The Operator Interface (OI), Model FCM2041-U3, is the central processor and user interface for each Cerberus PRO Modular system. Cerberus® PRO Modular system Operator Interface Model FCM2041-U3 Architect & Engineer Specifications Main-operator interface with userprompted lighted, large buttons for system control, operating sequence Large, 6-inch (15.2 cm) color display Touch-screen driven, system-control menus - Context-sensitive `Help’ button - Navigation buttons and `More Info’ - Additional tabs, including queues for mass notification (MNS) Go-to-beginning go-to-end queue buttons Front-end light-emitting diodes (LEDs) for `Alarm’ | `Supervisory’ | `Trouble’ commands - Partial-system disable LED - Audible Status LEDs (ON and Silenced) Global annunciation and control capability Integrated slots for switch-control (Model SCM-8) and LED-control (Model LCM-8) modules Mounts in any of one (1) of the following enclosures: - Model CAB1 (smallest cabinet) - Model CAB2 (medium cabinet) - Model CAB3 (largest cabinet) - Model REMBOX2 (two-module remote enclosure) - Model REMBOX4 - (four-module remote enclosure) 40 software-programmable `User Macro’ switches UL864 & CAN / ULC-S576 Listed - File S24304, Vol.
